فورک بولٹ آٹوموٹو فیوز کا چین سپلائر

Forkbolt auto fuses (also known as forkbolt fuses) are automotive fuses designed for high-current circuits. Their core parameters and characteristics are as follows:
میں. Core Parameters
‌Current Specifications‌
‌Small Forkbolt Type‌: 30A-150A (typical model ANS-B)
‌Large Forkbolt Type‌: 40A-800A (some models support 500A and above)
‌Voltage Rating‌
Compatible with 32V or 125V DC systems
‌Physical Dimensions‌
Typical dimensions of small size: 12×41×8.5mm (with D5.5mm mounting holes)

ANS Small Fork Bolt Car Fuse Kit- DC Forklift Modified 20A-200A for Car Truck Bus

اشتہار بولٹ آن, اے این ایم فلیٹ بیڈ, اور AML فورک بولٹ اعلی موجودہ کار فیوز

anl, جواب, اور اے این ایم چھوٹی کانٹا بولٹ کار کاروں کے لئے فیوز, ٹرک, اور بسیں اور بولنے والے

ii. Structural Characteristics
‌Connection Method‌
Bolt-on fastening increases the contact area by 300% compared to blade-type fuses, reducing the risk of loose connections.
‌Fusing Characteristics‌
Most fuses are slow-blow, capable of withstanding short-duration surges of up to 7 اوقات کی درجہ بندی کی موجودہ (such as those used for motor starting).
‌Material‌
رہائش: PBT flame-retardant material
Conductor: Copper alloy with gold plating/zinc alloy, strong oxidation resistance

iii. Typical Application Scenarios
Heavy-Duty Vehicles: Truck and Bus Starter Motors (over 300A)
Modified Circuits: High-Power Audio Systems, Inverters (100-200a)
New Energy Vehicles: High-Voltage Power Distribution Systems (125V/150A)

iv. Selection Considerations
Matching Principles
Must be compatible with the original vehicle fuse holder (جیسے, ANS-200/300).
Installation Requirements
Use a torque wrench to tighten the bolts (5-8 N·m recommended).
Replacement Risks
Misuse of blade-type fuses may result in poor contact and fire.

وی. Examples of Mainstream Models

نوٹ: When replacing, consult the vehicle maintenance manual first. Do not use fuses that exceed the specified fuse specification.
