NTC030HF01 - Carel PT100 NTC సెన్సార్ చైనా ఒరిజినల్ తయారీదారు - ఉష్ణోగ్రత సెన్సార్, ఉష్ణ స్విచ్, థర్మోస్టాట్ సరఫరాదారు

Carel NTC030HF01 అనేది HVAC/R కోసం NTC ఉష్ణోగ్రత సెన్సార్ (వేడి చేయడం, వెంటిలేషన్, ఎయిర్ కండిషనింగ్, మరియు శీతలీకరణ) వ్యవస్థలు. ఇది చైనాలో సిమెన్స్ మరియు హనీవెల్ వంటి బ్రాండ్లచే తయారు చేయబడింది. దయచేసి NTC030HF01 కోసం డ్రాయింగ్‌లు మరియు పారామితులను చూడండి.

సరళంగా చెప్పాలంటే, it’s a “ఉష్ణోగ్రత ప్రోబ్” with a 3-meter cable. To help you quickly determine its suitability, I have summarized the core parameters as follows:

Main Features and Application Scenarios

Parameter Items	Detailed Information
బ్రాండ్	Carel
Product Type	Passive NTC Temperature Sensor，(Rts) Pt100, PT1000
Temperature Sensing Element	Ntc (Negative Temperature Coefficient Thermistor), 10 kΩ @ 25°C, Beta value 3435，Pt100，PT1000
కొలిచే పరిధి	-50 కు +90 ° C. (some sources mention up to +105 °C in air)
Installation Method	Strap-on type for securing the sensor to the pipe surface
కేబుల్ పొడవు	3 మీటర్లు (flat black cable)
రక్షణ రేటింగ్	IP67 (dustproof and briefly submersible)
కనెక్షన్	Stripped ends, 2-core wire

The main feature of this sensor’s design is its clamp-on mounting design, making it ideal for measuring the temperature of the outer walls of pipes, such as refrigerant lines, నీటి పైపులు, or other pipes in HVAC systems.

Another advantage is its high IP67 protection rating, meaning it is effectively dustproof and waterproof, and can operate reliably in humid industrial environments, even those occasionally exposed to water.

NTC030HF01 – Carel NTC SENSOR, PT100 Drawings

One important information discrepancy to note:

There is a misleading piece of information in the search results: some websites incorrectly describe “NTC030HF01” as a PLC (Programmable Logic Controller). This is clearly an information entry error, as at least eight sources from different distributors consistently confirm that it is an NTC temperature sensor. అందువల్ల, please refer to the sensor parameters in this reply when making references.

Selection Recommendations:

If you need to use it to upgrade or repair Carel equipment, you can simply replace it. If you want to use it with controllers from other brands (such as Siemens, హనీవెల్, etc.లు), you can also do so, but you must ensure that the controller is compatible with the NTC 10k sensor; otherwise, the readings will be inaccurate. For pipe temperature measurement scenarios, the clamp-on design of this sensor is very convenient for installation; అయితే, it is not the ideal choice for measuring air temperature.

If needed, I can guide you on how to test the quality of this sensor or help you find a compatible controller model.
