The Carel NTC030HF01 is an NTC temperature sensor for HVAC/R (गरम करना, Ventilation, Air Conditioning, and Refrigeration) systems. It is manufactured in China by brands such as Siemens and Honeywell. Please refer to the drawings and parameters for the NTC030HF01.

सीधे शब्दों में कहें, it’s a “temperature probe” with a 3-meter cable. To help you quickly determine its suitability, I have summarized the core parameters as follows:

Main Features and Application Scenarios

Parameter Items	Detailed Information
ब्रांड	Carel
उत्पाद का प्रकार	Passive NTC Temperature Sensor，(आरटीएस) PT100, पीटी1000
Temperature Sensing Element	एनटीसी (Negative Temperature Coefficient Thermistor), 10 kΩ @ 25°C, बीटा मान 3435，PT100，पीटी1000
Measuring Range	-50 को +90 डिग्री सेल्सियस (some sources mention up to +105 °C in air)
Installation Method	Strap-on type for securing the sensor to the pipe surface
केबल लंबाई	3 मीटर की दूरी पर (flat black cable)
सुरक्षा रेटिंग	आईपी67 (dustproof and briefly submersible)
संबंध	Stripped ends, 2-core wire

The main feature of this sensor’s design is its clamp-on mounting design, making it ideal for measuring the temperature of the outer walls of pipes, such as refrigerant lines, water pipes, or other pipes in HVAC systems.

Another advantage is its high IP67 protection rating, meaning it is effectively dustproof and waterproof, and can operate reliably in humid industrial environments, even those occasionally exposed to water.

NTC030HF01 – Carel NTC SENSOR, PT100 Drawings

One important information discrepancy to note:

There is a misleading piece of information in the search results: some websites incorrectly describe “NTC030HF01” as a PLC (Programmable Logic Controller). This is clearly an information entry error, as at least eight sources from different distributors consistently confirm that it is an NTC temperature sensor. इसलिए, please refer to the sensor parameters in this reply when making references.

चयन सिफ़ारिशें:

If you need to use it to upgrade or repair Carel equipment, you can simply replace it. If you want to use it with controllers from other brands (such as Siemens, हनीवेल, वगैरह।), you can also do so, but you must ensure that the controller is compatible with the NTC 10k sensor; otherwise, the readings will be inaccurate. For pipe temperature measurement scenarios, the clamp-on design of this sensor is very convenient for installation; तथापि, it is not the ideal choice for measuring air temperature.

If needed, I can guide you on how to test the quality of this sensor or help you find a compatible controller model.
